LED 6-way Dupont Distributor Box,6-way Dupont Juction Box|2Pin Connectors

DC12V 24V Power Junction Box 6 Hole 10 Hole Led DuPont Junction Box LED Under Cabinet Wardrobe Closet Light DuPont Connector
Art.No : zp-6way
Rated values :Max.5A 12V/24V DC
Materials :ABS
Approvalse :CE,RoHS,Reach
Cable :VDE H03VVH2-F 2*0.5/2*0.75mm²
UL2468 AWG18awg
Color :white/black
Dimensions :38mm(L) x 59mm(W) x 10mm(H)
Applications :Spot Light,Down Light,Strip Light,Bar Light,Glass Edge Light,Task Light
6way :
Availability:
Quantity:
  • ZP-6way

  • ZP

BB

DC12V 24V Power Junction Box 6 Hole 5A Led DuPont Junction Box LED Under Cabinet Wardrobe Closet Light DuPont Connector

High-quality connectors for connecting LED lamps in the energy-saving era, one-to-one led six-way DuPont junction box cabinet lighting, using ABS high-quality shell,

strong heat resistance, applicable temperature range: -20℃~+50℃. Using DuPont 2.54 interface six-position junction box, single-hole output current can reach 3A.

The tail wiring can be customized according to customer requirements (line length, wire gauge, etc.).



Product name LED six-hole junction box

Product brand Zhongpu

Product model L8606

Material ABSPA765

Interface type DuPont 2.54

Insulation voltage 300V

Appearance size 58.5*38*10mm

Electrical conductivity 1.673×10-6Q·cm

Wire diameter (outer diameter) 1.5~2.0mm

Wire diameter (inner diameter) 0.5~1.0mm

Upper interface size 2.54 Lower interface size 2.54

Access certification CE/RoHS

6 way led junction box for under cabinet lighting

Rated values :Max.5A 12V/24V DC

Materials :ABS

Approvalse :CE,RoHS,Reach

Cable :VDE H03VVH2-F 2*0.75mm²

UL2468 AWG18awg

Color :white/black

QQ20250427-111911微信截图_202504271118056way

A
